Russia Type Pendulum Concrete Vibrator

Russia Type Pendulum Concrete Vibrator

Russia type pendulum concrete vibrator is specially used in Russia, Ukraine, Kazakhstan, etc. It is different with other regions used type. T-Flex could supply Russia market needed drive unit and vibrator poker with flex shaft.
inquiry

DETAILS

  • Russia Type Pendulum Concrete Vibrator
  • Russia Type Pendulum Concrete Vibrator
  • Russia Type Pendulum Concrete Vibrator

Russia type pendulum concrete vibrator is specially used in Russia, Ukraine, Kazakhstan, etc. It is different with other regions used type. T-Flex could supply Russia market needed drive unit and vibrator poker with flex shaft. Our concrete vibrator poker head with flexible shaft is designed for the internal vibration and compaction of fresh concrete with self-adjusting device to make the its work more stable.

Feature

LONG REACH
A lengthy 6-meter hose provides excellent reach around the worksite, giving the operator more control.


DESIGNED TO PERFORM
The conical shape of the pendulum raceway increases the friction area within the poker head to help maintain speed and prevent a loss in rpm.


BUILT TO LAST

The use of premium quality flexible shaft and steel reinforcement in the rubber hose contribute to a long service life.


SIMPLE, COST-EFFECTIVE MAINTENANCE
The overall simplicity of the design ensures maintenance is easy and inexpensive.

parameters

No.

Model

Poker head dia* length(mm)

Flexible shaft dia (mm)

Rubber hose dia(mm)

Rubber hose length(m)

RPM

Amplitude(mm)
Total value

Vibration Hz (V.P.M)

1

R28

28*380

10

26

2m, 4m, 5m, 5.5m, 6m, 9m,10m  (can be optional)

2850

1.4

183~200(11,000~12,000)

2

R38

38*430

13

36

2850

1.7

3

R51

51*400

13

36

2850

2.2

4

R76

76*430

13

36

2850

2.5
