High-end( Australia Type) Flex Drive Pump

Compared to the Economical flex drive pump, the High-end (Australia type) flex drive pump is designed with bigger flow capacity and bigger flex shaft and rubber hose assembly to supply more heavy-duty power in some harsh work site.

inquiry

DETAILS

Feature

1, Complete aluminum pump housing makes product lighter and better rust-proof performance

2, Heavy duty & double row bearings are designed to get high durability and easy maintenance

3, Oil bath lubrication

4, Lifting eyelets

5, Hardened steel wear plates

6, Heavy duty coke resistant cast iron impeller

7, 28mm solids pumping capacity

8, Seven oil seals for superior bearing protection

9, Quick action camlock hose fittings

parameters

Item	Model No.	TF P50A	TF P50A
Pump specification	Outlet size (mm)	50.8(2")	50.8(2")
	Max lift（m）	26	26
	Max flow capacity (m³/h）	63	63
	Body material	Aluminum	Iron
Hose & Flexible shaft specification	Hose outer diameter(mm)	38
	Hose inner diameter (mm)	21
	Flexible shaft diamter(mm)	15
	Length (m)	4~15
Drive unit	Honda GX160 Petrol/ Robin EY20 Petrol/ Yanmar L48N Diesel/ Other economical engines optional
