Backpack Petrol Eccentric Concrete Vibrator

Backpack Petrol Eccentric Concrete Vibrator

Powerful, ergonomic design, easily-operated, Flex-BP backpack petrol concrete vibrator plays quite a remarkable role in diverse work-sites where mobility, long-time power output needed but electricity unavailable.
inquiry

DETAILS

  • Backpack Petrol Eccentric Concrete Vibrator
  • Backpack Petrol Eccentric Concrete Vibrator
  • Backpack Petrol Eccentric Concrete Vibrator

Powerful, ergonomic design, easily-operated, Flex-BP backpack petrol concrete vibrator plays quite a remarkable role in diverse work-sites where mobility, long-time power output needed but electricity unavailable.


Feature

SAFETY

Flex-BP series is powered by a petrol engine and it doesn’t need any electricity connection, increasing worker operating safety.


MOBILITY

As no electricity needed, Flex-BP allows a great mobility for operators in work site.



ERGONOMIC DESIGN

Flex-BP series offer an ergonomic design where the engine weight is properly supported by the operator’s hips and a soft belt to improve operator’s comfort. By reducing operator fatigue and discouraging injury-prone postures, Flex-BP improves overall work site productivity.


EASY HANDLING AND CONTROL

Throttle controller and on/off switch are integrated into the handle, which makes handling and vibrator control easier.


EXTENDED USE LIFE

Flex-BP equipped by specially-designed engine mount includes shear resistant isolators and a reinforced base plate.

Flex-BP equipped with premium transmission flex shaft and rubber hoses; which best steel wires and top-quality rubber and reinforced ends used, provide higher resistance to withstand more intense bending.

Eccentric poker heads are processed by the modern CNC center to ensure detail accuracy. And double seal prevents the entrance of lubricants.

From engines and each part, Flex-BP supply professional solution to extend concrete vibrator’s use life.

parameters

MODEL

BP25/35/45

Drive unit

Honda GX35/Other optional economic engine

Fuel type

Petrol

Vibrator head diameter&Length

mm

25*380
35*410
45*385

Hose Length

m

 2/3

Hose outer diameter

mm

21/27/27

Flex shaft core diameter

mm

8/9.15/9.15

Frequency

vpm

10,000

Optional polyurethane tipped

Yes
